How do I add a detail callout in Revit?
In a project, click View tab Create panel (Callout). In the Type Selector, select the type of callout to create: a detail callout or a view callout (a callout view that has the same view type as the parent view). See Callout Types. On the Options Bar, for Scale, select a scale for the callout view.
What are drafting views Revit?
In a drafting view, you create details at differing view scales (coarse, medium, or fine) and use 2D detailing tools: detail lines, detail regions, detail components, insulation, reference planes, dimensions, symbols, and text. These are the exact same tools used in creating a detail view.
What is the primary reason for creating a callout view?
A callout shows some portion of another view at a larger scale. In a construction document set, use callouts to provide an orderly progression of labeled views at increasing levels of detail. See an enlarged view of a specified part of a model.
How do you create a callout family in Revit?
Create a Callout Head Family
- Click Create tab Text panel (Label).
- Move the cursor to the drawing area, and click where you want the information to display in the callout head.
- In the Edit Label dialog, under Category Parameters, select the field to place in the callout head.
- Click (Add parameters to label).
- Click OK.
What are drafting views?
How do I make a callout from a drafting view?
To create an enlarged view for a specific room/area within a larger plan – View>callout>draw callout. Pretty easy. To make a callout in a drafting view, do the same thing but make sure the “reference other view” box is checked before you draw the callout shape. You can also use this option to reference a drafting view from a floor/ceiling plan.
Do view callouts automatically duplicate model elements?
View callouts will only automatically duplicate model elements in a view, not annotation objects (which all drafting views are).
How do I add a second callout to a view?
The second callout needs to be set to “Reference other view” selecting the view from the drop down menu of the options bar. This needs to be done BEFORE placing the callout on the view. If you already placed the second callout without doing this, it’s too late.
