How do I update a vDisk Citrix Provisioning Server?

Updating a vDisk involves the following:

1. Create a version of the vDisk, manually or automatically.
2. Boot the newly created version from a device (maintenance device or update device), make and save any changes to the vDisk, then shut down the device.
3. Promote the new version to production.

How do I update my personal vDisk inventory?

Update an existing personal vDisk image

1. Create a version of the vDisk image.
2. Boot the VM from the vDisk image in Maintenance Mode.
3. Install updates on the new vDisk version.
4. Shut the VM down. Inventory runs automatically when the VM shuts down.
5. Promote the new version to either Test or Production.

How do I expand PVS vDisk with versions?

Expand vDisk VHD

1. Open cmd or powershell as administrator.
2. diskpart.
3. select vdisk file= “” (e.g. V:\store\my.vhd)
4. list vdisk (you should now see your vdisk and the path)
5. expand vdisk maximum=60000 (This is the size in megabytes of the size you want to extend, so 60000 is 60Gb)
6. attach vdisk.
7. list disk.

How do I disable Citrix personal vDisk?

To resolve this issue, Citrix recommends that you remove the personal vDisk before upgrading:

1. Select the appropriate copy of the vDisk installer from the XenApp/XenDesktop media.
2. Remove the personal vDisk installation.
3. Select Remove personal vDisk.
4. Click Finish.
5. The Reboot Requirement page appears.

How do I update PVS target device software?

Upgrade PVS target device software Copy the PVS_Device.exe or PVS_Device_x64.exe to the target device. Right click the installer and choose Run as administrator. Run the installer and choose all the options as you would install a fresh version. Click Finish to begin the upgrade.

What is vDisk in Citrix?

A vDisk acts as a hard disk for a target device and exists as disk image files on a Citrix Provisioning server or on a shared storage device. A vDisk consists of a VHDX base image file, any associated properties files, such as a . pvp file and if applicable, a chain of referenced VHDX differencing disks, . avhdx .

How do you update a PVS image?

pvs vDisk update process

1. Right click on a Standard Mode vDisk and choose version and create new version.
2. Set the update target device to maintenance mode.
3. Boot the target device VM in hypervisor.
4. Install windows updates, software updates and power off the updater target device.

How do I restart Citrix personal vDisk?

Reset a Personal vDisk

1. From the Help Desk view, choose the targeted Desktop OS machine.
2. From this view or in the Personalization panel of the User Details view, click Reset Personal vDisk.
3. Click Reset. A message appears warning that the user will be logged off.

What is vDisk in PVS?

What is vDisk storage?

The VDISK statement or command creates and initializes a virtual disk. VDISK creates either a shared memory object or a data space for each virtual disk. If there is enough space in the extended shared area, a memory object is created, if not a data space is created.

How do I create a vDisk in PVS?

Still in the PVS Console, choose the newly created target device, right-click and select Properties and change the Boot from option to vDisk. Right-click the target again and using the Active Directory drop-down menu, select Create Machine Account. Change boot device to PXE. Reboot target device.

What is Citrix personal vDisk?

Citrix Virtual Apps and Desktops with Personal vDisk technology is a high-performance enterprise desktop virtualization solution. This software makes the VDI accessible to workers who require personalized desktops, by using pooled-static virtual machines. The same users are assigned the same desktop for later sessions.

How do I create a new version of a vdisk?

Create a version of the vDisk, manually or automatically. Boot the newly created version from a device (maintenance device or update device), make and save any changes to the vDisk, then shut down the device. Promote the new version to production. The following illustrates the general promotion of a vDisk update:

How do I update a vdisk using the updater device?

Set the Updater device to boot from the Maintenance Type . This is used by the Versioning method of updating a vDisk. When adding the Updater device to Active Directory, be mindful of group policies. Sometimes it is helpful to apply the group policies to the Updater device so they are stored in the vDisk you are updating.

How do I upgrade a vdisk in Citrix provisioning?

This basically requires a separate Updater device for each vDisk. In the Citrix Provisioning Console, right-click a Standard Mode vDisk, and click Versions. In the vDisk Versions window, click New. Notice that the Access is set to Maintenance. Click Done.

How many maintenance devices can be assigned to a vdisk?

Multiple maintenance devices can be assigned to a vDisk. However, only one device can boot and access that version of the vDisk at any given time. During that time that maintenance device has exclusive read/write access. Automated Update – Creating automated updates saves administration time and physical resources.
