Is C3850 NM 4 1G hot-swappable?

All network modules are hot-swappable. C3850-NM-4-1G This module has four 1-Gigabit SFP module slots. Any combination of standard SFP modules are supported. SFP+ modules are not supported.

How much power does a Cisco 3850 draw?

The 3850 switch has multigigabit ports to support 1, 2.5, 5, and 10-Gbps speeds on select models. Power your solutions with support for PoE and PoE+ to provide up to 30W of power per port, or 60W of power per port with UPOE.

Is Cisco 3850 a PoE?

The Cisco Catalyst 3850 Series Switches support full IEEE 802.3at Power over Ethernet Plus (PoE+), Cisco Universal Power Over Ethernet (Cisco UPOE ®), modular and field-replaceable network modules, RJ-45 and fiber-based downlink interfaces, and redundant fans and power supplies.

Are Cisco network modules hot swappable?

The network module is hot-swappable. If you remove a module, replace it with another network module or a blank module. The switch complies with EMC, safety, and thermal specifications when a network module is present.

What is SFP vs SFP+?

The main difference between SFP and SFP+ is that the SFP+ is used in Gigabit Ethernet applications while SFP is for 100Bse or 1000Base applications. SFP+ transceivers use the same dimensions of pluggable transceivers in the 10Gbs Ethernet and 8.5Gbs fiber channel with SFP.

When you deploy Cisco Catalyst 3850 Series switches which two modes of operation can you choose from?

Cisco Catalyst 3850 Series Switches have two modes of operation, Install and Bundle.

Can SFP+ run at 1G?

Most SFP+ slots are backward compatible with SFP modules to run at 1G speed. However, the SFP slots on gigabit switch cannot support the 10G speed required by SFP+ modules. For instance, most Cisco and FS 10Gb switches support 10G SFP+ and 1G SFP optics on their SFP+ ports.

What is SFP+ stand for?

enhanced small form-factor pluggable
SFP+ means enhanced small form-factor pluggable, is an enhanced version of the SFP that supports data rates up to 16 Gbit/s. SFP+ supports 8 Gbit/s Fibre Channel, 10 Gigabit Ethernet and Optical Transport Network standard OTU2. It is a popular industry format supported by many network component vendors.

What is the c3850-nm-4-1g network module?

Network Module Overview. C3850-NM-4-1G. This module has four 1 G SFP module slots. Any combination of standard SFP modules are supported. SFP+ modules are not supported. If you insert an SFP+ module in the 1 G network module, the SFP+ module does not operate, and the switch logs an error message.

What interfaces are available for a Cisco 3850 switch?

It is sometimes confusing on which interfaces are available and which can be configured when using one of the NM modules in a Cisco 3850 Switch. We currently offer three different modules: C3850-NM-4-1G (four 1-Gigabit SFP module slots) C3850-NM-2-10G (Combination of 1-Gig and 10-Gig ports)

How many QSFP+ interfaces are supported on the c3850-nm-4-10g module?

Network modules with two 40 Gigabit Ethernet QSFP+ or eight 10 Gigabit Ethernet SFP+ interfaces The C3850-NM-4-10G module is supported only on the 48-port Gigabit Ethernet models or on the 12-port or higher 10 Gigabit Ethernet models.

What is the Cisco Systems expansion module for catalyst 3850-24?

The Cisco Systems Expansion Module for Catalyst 3850-24 is specially designed to support current and next-generation wireless speeds and standards on existing cabling infrastructure. This Gigabit switch expansion module has four SFP mini-GBIC ports.
