What does ES44DC stand for?
ES44DC (2005-2010) The ES44DC (Evolution Series, 4400 HP, DC traction) replaced the Dash 9-44CW model in the General Electric catalogue. Primary users are BNSF Railway, CSX Transportation, and Canadian National Railway. Pilbara Iron in Australia ordered a lengthened, international version designated ES44DCi.
How much does an ES44AC cost?
The new GE ES44AC locomotives, which cost $2.5 million each, are 18 percent more fuel efficient than other alternatives that IAIS looked into. Miller said one of the new 4,400-horsepower units will pull a train equivalent to what two or three of its current units can handle.
How long is a ES44AC?
Specifications
| Model | ES44AC | ET44AC |
|---|---|---|
| Wheel arrangement | C-C | C-C |
| Length | 73′ 2″ | 74′ 6″ (lengthened to accomodate cooling system and larger cab hood) |
| Weight | 416-432,000 lbs. | 426,000 lbs. |
| Height | 15′ 5″ | 16′ 1″ (over antennas) |
How long do locomotive engines last?
The Tier 4 locomotive is designed for a typical lifespan of 25 to 30 years.
What kind of locomotive is an ES44DC?
The GE (General Electric) ES44DC is a type of six-axle, 4,400hp diesel locomotive built from 2004 to 2008 (first introduced in 2003) with a total of at least 1,368 built. The model is part of GE’s “Evolution Series” (otherwise known as a “GEVO”). A typical CSX ES44DC (now classified as an “ES40DC”).
What is the difference between an ES40DC and an ES44AC?
The locomotive is virtually identical to the above ES40DC save for its increased horsepower using the 4-cycle, 12-cylinder GEVO prime mover. ES44AC: Rated at 4,400 hp, using AC traction, this model replaced the AC4400CW (also rated at 4,400 hp using AC traction).
How many axles does a GE es44 have?
GE ES44DC 1 Bio. The GE (General Electric) ES44DC is a type of six-axle, 4,400hp diesel locomotive built from 2004 to 2008 (first introduced in 2003) with a total of at least 1,368 2 History. 3 Versions. 4 Confusion. 5 Trivia/Facts. 6 Gallery.
What is the horsepower of the General Electric ES44DC?
General Electric ES44DC Data Sheet Information Compiled by: JEAN-DENIS BACHAND New: 27 October 2007 Drawing by: Jean-Denis Bachand Engine Builder: General Electric Engine: GEVO-12 (4-cycle) Bore & Stroke 250mm X 320mm RPM (Maximum / Minimum) 1050 / 450 Main Generator: GE – GMG196A Horsepower: 4400 Gear Ratio: 83:20 Speed: 70 mph
